ReadCell VS320-DPE industrial DPM handheld
A corded handheld for codes marked straight onto metal. It combines direct white light with diffuse red and blue light for reflective surfaces, and its Ethernet version talks to the PLC over PROFINET or EtherNet/IP.
Marks on metal, read by hand
Dot-peened and laser-etched codes on steel, aluminum and cast parts. The ReadCell VS320-DPE switches between direct and diffuse light, and a red cross-hair laser shows the operator where it is reading.
- Global shutter monochrome sensor, 1280 × 1024 at 60 fps
- Direct white light, diffuse red and blue light
- Dual-core high-performance processor with an in-house decoding algorithm for hard-to-read codes
- Ethernet version with TCP/IP, Modbus, PROFINET and EtherNet/IP
- Rugged design: 1.8 m drops to concrete, IP64 with cable connected
- Ergonomic design for comfortable use
Used in
Two hardware versions
Same optics, lighting and housing. The physical interface is chosen when you order.
Serial and USB
For a PC, a terminal or a serial host at the workstation.
- Interfaces
- RS232 · USB HID · USB COM
- Supply
- 5 VDC ±5%
- Current
- 450 mA operating · 120 mA standby
Industrial Ethernet
For stations where the reading goes straight to the PLC or MES.
- Protocols
- TCP/IP · Modbus · PROFINET · EtherNet/IP
- Supply
- 5 VDC; start-up from 4.7 V, start-up peak 450 mA
- Current
- 480 mA operating (peak 1100 mA) · 340 mA standby
Specifications
From the ReadCell VS320-DPE datasheet, revision F.
| Image sensor | Global shutter CMOS, monochrome |
|---|---|
| Resolution | 1280 × 1024 |
| Frame rate | 60 fps |
| Field of view | 29° × 23° (typical) |
| Focus | Fixed |
| Illumination | Direct white; diffuse red and blue |
| Aimer | Red cross-hair laser |
| 1D | Codabar, Code 39, Interleaved 2 of 5, NEC 2 of 5, Code 93, Straight 2 of 5 Industrial, Straight 2 of 5 IATA, Matrix 2 of 5, Code 11, Code 128, GS1-128, UPC-A, UPC-E0, UPC-E1, EAN/JAN-13, EAN/JAN-8, MSI, GS1 DataBar Omnidirectional, GS1 DataBar Limited, GS1 DataBar Expanded, China Post (Hong Kong 2 of 5), Korea Post |
|---|---|
| 2D and stacked | QR Code, Data Matrix, PDF417, MicroPDF417, Aztec, MaxiCode, Han Xin, GS1 Composite, Codablock A, Codablock F |
| Code 128, 7 mil | 20–100 mm |
|---|---|
| Code 128, 13 mil | Up to 140 mm (near limit set by field of view) |
| Data Matrix, 3 mil | 25–50 mm |
| Data Matrix, 5 mil | 15–90 mm |
| QR Code, 3 mil | 25–45 mm |
| QR Code, 5 mil | 20–80 mm |
Test conditions: 25 °C, ambient light 200–300 lux, grade-A test codes.
| Interfaces | RS232 · USB HID · USB COM · Ethernet (by hardware version) |
|---|---|
| Protocols, Ethernet version | TCP/IP · Modbus · PROFINET · EtherNet/IP |
| Trigger | Button or continuous |
| Configuration software | IDManager |
| Power supply | 5 VDC ±5% |
|---|---|
| Current, USB / RS232 | 450 mA operating · 120 mA standby |
| Current, Ethernet | 480 mA operating, 1100 mA peak · 340 mA standby; start-up from 4.7 V |
| Dimensions | 191.8 × 76.9 × 130.2 mm |
| Weight | 360 g including cable |
| Housing | High-performance plastic |
| Protection | IP64 with cable connected |
| Drop | 1.8 m to concrete |
| Operating temperature | −10 to 50 °C |
| Storage temperature | −20 to 70 °C |
| Humidity | 5% to 85% RH, non-condensing |
Connect it to your PLC
All integration guidesOrder the Ethernet version of the ReadCell VS320-DPE and the reading goes straight to the PLC.
Files
The datasheet downloads directly. The other files we send by email on request.
VS320-DPE questions
Which version should I order?
The USB / RS232 version for a PC or serial host at the workstation. The Ethernet version if the reading should go to a PLC over PROFINET, EtherNet/IP or Modbus, or to a host over TCP/IP. The interface is fixed in hardware, so tell us which one when you order.
What kind of marks does it read?
Printed labels and codes marked directly on parts. Direct white light suits matte surfaces; diffuse red and blue light suit reflective ones. A 5 mil Data Matrix reads from 15 to 90 mm.
How is it powered?
5 VDC ±5%. The USB / RS232 version draws about 450 mA when operating, the Ethernet version about 480 mA.
Can it carry our brand?
Yes. See OEM and private label for the options; MOQ is quoted per project.
Quote a ReadCell VS320-DPE.
Tell us the quantity, the interface version and the parts you read.
